Referentieontwerp zoeken (IC-fabrikant)

Onze referentielijst laat zien met welke IC's onze kristallen onder andere gebruikt kunnen worden. Natuurlijk zijn voor het klokken van andere IC's geschikte kristallen - met zeer lage weerstand voor zeer snelle en betrouwbare oscillatie - beschikbaar uit ons bijzonder brede en diepe productassortiment. Voor nieuwe ontwikkelingen raden we MHz-kristallen uit de SMD03025/4 (3,2x2,5mm/4pad) of SMD2016/4 (2,0x1,6/4mm) series aan. Het SMD03025/4-serie SMD-kristal is momenteel het goedkoopste geminiaturiseerde SMD-kristal en het SMD02016/4-serie SMD-kristal wordt gebruikt in toepassingen waarvoor de SMD03025/4 te groot is. Wij raden ook de volgende SMD oscillerende kristallen aan: SMD02016/4US en SMD03025/4US voor het ultrasone afdichtingsproces.

Bel ons!Neem contact met ons op via e-mail!Bel me alstublieft terug!

Manufacturer	IC	Package	Frequency	CL	ESR	Product Number	Data Sheet	Sample	Product

STM	STM32WL3X	2.0 x 1.6 mm	48.000 MHz	8 pF	30 Ω	MD02016/4 48.000 MHZ 10/10/-20+70/8PF	PDF	Request	Enquiry
Infineon	TDA5240	5.0 x 3.2 mm	21.948717 MHz	12 pF	60 Ω	SMD0503/4 21.948717 MHz 10/15/-40+85/12pF	PDF	Request	Enquiry
Infineon	TDA5235	5.0 x 3.2 mm	21.948717 MHz	12 pF	60 Ω	SMD0503/4 21.948717 MHz 10/15/-40+85/12pF	PDF	Request	Enquiry
Infineon	TDA5225	5.0 x 3.2 mm	21.948717 MHz	12 pF	60 Ω	SMD0503/4 21.948717 MHz 10/15/-40+85/12pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	50.000 MHz	12 pF	25 Ω	SMD02016/4 50.000 MHz 10/20/-40+85/12pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	50.000 MHz	12 pF	25 Ω	SMD02016/4 50.000 MHz 10/20/-40+85/12pF	PDF	Request	Enquiry
NXP	RT600	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R	PDF	Request	Enquiry
NXP	RT600	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R	PDF	Request	Enquiry
NXP	RT600	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R	PDF	Request	Enquiry
NXP	RT600	3.2 x 2.5 mm	32.000 MHz	8 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
NXP	RT600	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
NXP	RT600	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
NXP	QN908x	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R	PDF	Request	Enquiry
NXP	QN908x	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R	PDF	Request	Enquiry
NXP	QN908x	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R	PDF	Request	Enquiry
NXP	QN908x	3.2 x 2.5 mm	32.000 MHz	8 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
NXP	QN908x	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
NXP	QN908x	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
NXP	QN908x	3.2 x 1.5 mm	32.768 kHz	6pF	50 kΩ	M3215RR 32.768 kHz ±20 ppm 6pF (-40/+85°C)	PDF	Request	Enquiry
NXP	QN908x	3.2 x 1.5 mm	32.768 kHz	7 pF	50 kΩ	M3215RR 32.768 kHz ±20 ppm 7pF (-40/+85°C)	PDF	Request	Enquiry
NXP	QN908x	3.2 x 1.5 mm	32.768 kHz	9pF	50 kΩ	M3215RR 32.768 kHz ±20 ppm 9pF (-40/+85°C)	PDF	Request	Enquiry
NXP	QN9090	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R	PDF	Request	Enquiry
NXP	QN9090	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R	PDF	Request	Enquiry
NXP	QN9090	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R	PDF	Request	Enquiry
NXP	QN9090	3.2 x 2.5 mm	32.000 MHz	8 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
NXP	QN9090	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
NXP	QN9090	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
NXP	QN9090	3.2 x 1.5 mm	32.768 kHz	6pF	50 kΩ	M3215RR 32.768 kHz ±20 ppm 6pF (-40/+85°C)	PDF	Request	Enquiry
NXP	QN9030	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R	PDF	Request	Enquiry
NXP	QN9030	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R	PDF	Request	Enquiry
NXP	QN9030	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R	PDF	Request	Enquiry
NXP	QN9030	3.2 x 2.5 mm	32.000 MHz	8 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
NXP	QN9030	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
NXP	QN9030	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
NXP	QN9030	3.2 x 1.5 mm	32.768 kHz	6pF	50 kΩ	M3215RR 32.768 kHz ±20 ppm 6pF (-40/+85°C)	PDF	Request	Enquiry
NXP	NHS52S04	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R	PDF	Request	Enquiry
NXP	NHS52S04	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R	PDF	Request	Enquiry
NXP	NHS52S04	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R	PDF	Request	Enquiry
NXP	NHS52S04	3.2 x 2.5 mm	32.000 MHz	8 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
NXP	NHS52S04	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
NXP	NHS52S04	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
NXP	NHS52S04	3.2 x 1.5 mm	32.768 kHz	6pF	50 kΩ	M3215RR 32.768 kHz ±20 ppm 6pF (-40/+85°C)	PDF	Request	Enquiry
NXP	NHS52S04	3.2 x 1.5 mm	32.768 kHz	7 pF	50 kΩ	M3215RR 32.768 kHz ±20 ppm 7pF (-40/+85°C)	PDF	Request	Enquiry
NXP	NHS52S04	3.2 x 1.5 mm	32.768 kHz	9pF	50 kΩ	M3215RR 32.768 kHz ±20 ppm 9pF (-40/+85°C)	PDF	Request	Enquiry
Texas Instruments	CC1310	1.6 x 1.2 mm	24.000 MHz	8 pF	70 Ω	SMD01612/4 24.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Texas Instruments	CC1310	2.0 x 1.6 mm	24.000 MHz	8 pF	60 Ω	SMD02016/4 24.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Texas Instruments	CC1310	3.2 x 2.5 mm	24.000 MHz	8 pF	30 Ω	SMD03025/4 24.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Texas Instruments	CC1310	1.6 x 1.0 mm	32.768 kHz	7 pF	90 kΩ	M1610 32.768 kHz ±20 ppm 7pF (-40/+85°C)	PDF	Request	Enquiry
Texas Instruments	CC1310	3.2 x 1.5 mm	32.768 kHz	7 pF	50 kΩ	M3215RR 32.768 kHz ±20 ppm 7pF (-40/+85°C)	PDF	Request	Enquiry
Texas Instruments	CC23xx	1.6 x 1.0 mm	32.768 kHz	7 pF	90 kΩ	M1610 32.768 kHz ±20 ppm 7pF (-40/+85°C)	PDF	Request	Enquiry
Texas Instruments	CC23xx	3.2 x 1.5 mm	32.768 kHz	7 pF	50 kΩ	M3215RR 32.768 kHz ±20 ppm 7pF (-40/+85°C)	PDF	Request	Enquiry
Texas Instruments	CC26xx	1.6 x 1.0 mm	32.768 kHz	7 pF	90 kΩ	M1610 32.768 kHz ±20 ppm 7pF (-40/+85°C)	PDF	Request	Enquiry
Texas Instruments	CC26xx	3.2 x 1.5 mm	32.768 kHz	7 pF	50 kΩ	M3215RR 32.768 kHz ±20 ppm 7pF (-40/+85°C)	PDF	Request	Enquiry
Texas Instruments	CC26xx	2.0 x 1.6 mm	48.000 MHz	7 pF	20 Ω	SMD02016/4 48.000 MHz 10/20/-40+85/7pF	PDF	Request	Enquiry
Texas Instruments	CC2652R	2.0 x 1.6 mm	48.000 MHz	8 pF	40 Ω	SMD02016/4 48.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
Texas Instruments	CC2652R	2.0 x 1.6 mm	48.000 MHz	8 pF	40 Ω	SMD02016/4 48.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
Texas Instruments	CC2652R	2.0 x 1.6 mm	48.000 MHz	8 pF	40 Ω	SMD02016/4 48.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Texas Instruments	CC2652R	3.2 x 2.5 mm	48.000 MHz	8 pF	25 Ω	SMD03025/4 48.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
Texas Instruments	CC2652R	3.2 x 2.5 mm	48.000 MHz	8 pF	25 Ω	SMD03025/4 48.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
Texas Instruments	CC2652R	3.2 x 2.5 mm	48.000 MHz	8 pF	25 Ω	SMD03025/4 48.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Texas Instruments	CC13xx	2.0 x 1.6 mm	48.000 MHz	7 pF	20 Ω	SMD02016/4 48.000 MHz 10/20/-40+85/7pF	PDF	Request	Enquiry
Texas Instruments	CC2642R	2.0 x 1.6 mm	48.000 MHz	8 pF	40 Ω	SMD02016/4 48.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Texas Instruments	CC2642R	2.0 x 1.6 mm	48.000 MHz	8 pF	40 Ω	SMD02016/4 48.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
Texas Instruments	CC2642R	2.0 x 1.6 mm	48.000 MHz	8 pF	40 Ω	SMD02016/4 48.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
Texas Instruments	CC2642R	3.2 x 2.5 mm	48.000 MHz	8 pF	25 Ω	SMD03025/4 48.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
Texas Instruments	CC2642R	3.2 x 2.5 mm	48.000 MHz	8 pF	25 Ω	SMD03025/4 48.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
Texas Instruments	CC2642R	3.2 x 2.5 mm	48.000 MHz	8 pF	25 Ω	SMD03025/4 48.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Qualcomm	Snapdragon	2.0 x 1.6 mm	48.000 MHz	8.8 pF	20 Ω	SMD02016/4 48.000 MHZ 10/15/-40+85/8.8PF	PDF	Request	Enquiry
Nordic	nRF51822	3.2 x 1.5 mm	32.768 kHz	9pF	50 kΩ	M3215RR 32.768 kHz ±20 ppm 9pF (-40/+85°C)	PDF	Request	Enquiry
Nordic	nRF51822	3.2 x 1.5 mm	32.768 kHz	12.5 pF	50 kΩ	M3215RR 32.768 kHz ±20 ppm 12.5pF (-40/+85°C)	PDF	Request	Enquiry
Nordic	nRF51822	2.0 x 1.6 mm	16.000 MHz	8 pF	150 Ω	SMD02016/4 16.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Nordic	nRF51822	2.0 x 1.6 mm	16.000 MHz	10 pF	150 Ω	SMD02016/4 16.000 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Nordic	nRF51822	2.0 x 1.6 mm	16.000 MHz	12 pF	150 Ω	SMD02016/4 16.000 MHz 10/20/-40+85/12pF	PDF	Request	Enquiry
Nordic	nRF51822	2.0 x 1.6 mm	32.000 MHz	8 pF	60 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Nordic	nRF51822	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Nordic	nRF51822	3.2 x 2.5 mm	32.000 MHz	10 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Nordic	nRF51822	3.2 x 2.5 mm	32.000 MHz	12 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/12pF	PDF	Request	Enquiry
Nordic	nRF52	2.0 x 1.6 mm	32.000 MHz	8 pF		SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R	PDF	Request	Enquiry
Nordic	nRF53	2.0 x 1.6 mm	32.000 MHz	8 pF		SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R	PDF	Request	Enquiry
Nordic	nRF52832	3.2 x 2.5 mm	32.000 MHz	8 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
Nordic	nRF52832	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
Nordic	nRF52832	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Nordic	nRF52832	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R	PDF	Request	Enquiry
Nordic	nRF52832	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R	PDF	Request	Enquiry
Nordic	nRF52832	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R	PDF	Request	Enquiry
Nordic	nRF52811	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R	PDF	Request	Enquiry
Nordic	nRF52811	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R	PDF	Request	Enquiry
Nordic	nRF52811	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R	PDF	Request	Enquiry
Nordic	nRF52811	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Nordic	nRF52811	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
Nordic	nRF52811	3.2 x 2.5 mm	32.000 MHz	8 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
Nordic	nRF51822	2.0 x 1.6 mm	32.000 MHz	10 pF	60 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Nordic	nRF5340	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R	PDF	Request	Enquiry
Nordic	nRF5340	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R	PDF	Request	Enquiry
Nordic	nRF5340	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R	PDF	Request	Enquiry
Nordic	nRF5340	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Nordic	nRF5340	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
Nordic	nRF5340	3.2 x 2.5 mm	32.000 MHz	8 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
Silicon Labs	EFR32BG21	3.2 x 2.5 mm	38.400 MHz	10 pF	35 Ω	SMD03025/4 38.400 MHz 10/10/-20+70/10pF	PDF	Request	Enquiry
Silicon Labs	EFR32BG21	3.2 x 2.5 mm	38.400 MHz	10 pF	35 Ω	SMD03025/4 38.400 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Silicon Labs	EFR32BG21	2.0 x 1.6 mm	38.400 MHz	10 pF	55 Ω	SMD02016/4 38.400 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Silicon Labs	EFR32MG21	3.2 x 2.5 mm	38.400 MHz	10 pF	35 Ω	SMD03025/4 38.400 MHz 10/10/-20+70/10pF	PDF	Request	Enquiry
Silicon Labs	EFR32MG21	3.2 x 2.5 mm	38.400 MHz	10 pF	35 Ω	SMD03025/4 38.400 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Silicon Labs	EFR32MG21	2.0 x 1.6 mm	38.400 MHz	10 pF	55 Ω	SMD02016/4 38.400 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Silicon Labs	EFR32MG22	3.2 x 2.5 mm	38.400 MHz	10 pF	35 Ω	SMD03025/4 38.400 MHz 10/10/-20+70/10pF	PDF	Request	Enquiry
Silicon Labs	EFR32MG22	3.2 x 2.5 mm	38.400 MHz	10 pF	35 Ω	SMD03025/4 38.400 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Silicon Labs	EFR32MG22	2.0 x 1.6 mm	38.400 MHz	10 pF	55 Ω	SMD02016/4 38.400 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Silicon Labs	EFR32FG22	3.2 x 2.5 mm	38.400 MHz	10 pF	35 Ω	SMD03025/4 38.400 MHz 10/10/-20+70/10pF	PDF	Request	Enquiry
Silicon Labs	EFR32FG22	3.2 x 2.5 mm	38.400 MHz	10 pF	35 Ω	SMD03025/4 38.400 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Silicon Labs	EFR32FG22	2.0 x 1.6 mm	38.400 MHz	10 pF	55 Ω	SMD02016/4 38.400 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Decawave	DW1000	2.0 x 1.6 mm	38.400 MHz	8 pF	50 Ω	SMD02016/4 38.400 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
Decawave	DW1000	2.0 x 1.6 mm	38.400 MHz	8 pF	50 Ω	SMD02016/4 38.400 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
Decawave	DW1000	2.0 x 1.6 mm	38.400 MHz	8 pF	50 Ω	SMD02016/4 38.400 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Decawave	DW1000	3.2 x 2.5 mm	38.400 MHz	8 pF	35 Ω	SMD03025/4 38.400 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
Decawave	DW1000	3.2 x 2.5 mm	38.400 MHz	8 pF	35 Ω	SMD03025/4 38.400 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
Decawave	DW1000	3.2 x 2.5 mm	38.400 MHz	8 pF	35 Ω	SMD03025/4 38.400 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Semtech	SX1261	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R	PDF	Request	Enquiry
Semtech	SX1261	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R	PDF	Request	Enquiry
Semtech	SX1261	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R	PDF	Request	Enquiry
Semtech	SX1261	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R	PDF	Request	Enquiry
Semtech	SX1261	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R	PDF	Request	Enquiry
Semtech	SX1261	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R	PDF	Request	Enquiry
Semtech	SX1261	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
Semtech	SX1261	3.2 x 2.5 mm	32.000 MHz	8 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
Semtech	SX1261	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Semtech	SX1261	3.2 x 2.5 mm	32.000 MHz	10 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1261	3.2 x 2.5 mm	32.000 MHz	10 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/10pF	PDF	Request	Enquiry
Semtech	SX1261	3.2 x 2.5 mm	32.000 MHz	10 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1262	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R	PDF	Request	Enquiry
Semtech	SX1262	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R	PDF	Request	Enquiry
Semtech	SX1262	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R	PDF	Request	Enquiry
Semtech	SX1262	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R	PDF	Request	Enquiry
Semtech	SX1262	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R	PDF	Request	Enquiry
Semtech	SX1262	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R	PDF	Request	Enquiry
Semtech	SX1262	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
Semtech	SX1262	3.2 x 2.5 mm	32.000 MHz	8 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
Semtech	SX1262	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Semtech	SX1262	3.2 x 2.5 mm	32.000 MHz	10 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1262	3.2 x 2.5 mm	32.000 MHz	10 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/10pF	PDF	Request	Enquiry
Semtech	SX1262	3.2 x 2.5 mm	32.000 MHz	10 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1268	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R	PDF	Request	Enquiry
Semtech	SX1268	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R	PDF	Request	Enquiry
Semtech	SX1268	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R	PDF	Request	Enquiry
Semtech	SX1268	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R	PDF	Request	Enquiry
Semtech	SX1268	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R	PDF	Request	Enquiry
Semtech	SX1268	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R	PDF	Request	Enquiry
Semtech	SX1268	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
Semtech	SX1268	3.2 x 2.5 mm	32.000 MHz	8 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
Semtech	SX1268	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Semtech	SX1268	3.2 x 2.5 mm	32.000 MHz	10 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1268	3.2 x 2.5 mm	32.000 MHz	10 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/10pF	PDF	Request	Enquiry
Semtech	SX1268	3.2 x 2.5 mm	32.000 MHz	10 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1272	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R	PDF	Request	Enquiry
Semtech	SX1272	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R	PDF	Request	Enquiry
Semtech	SX1272	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R	PDF	Request	Enquiry
Semtech	SX1272	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R	PDF	Request	Enquiry
Semtech	SX1272	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R	PDF	Request	Enquiry
Semtech	SX1272	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R	PDF	Request	Enquiry
Semtech	SX1272	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
Semtech	SX1272	3.2 x 2.5 mm	32.000 MHz	8 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
Semtech	SX1272	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Semtech	SX1272	3.2 x 2.5 mm	32.000 MHz	10 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1272	3.2 x 2.5 mm	32.000 MHz	10 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/10pF	PDF	Request	Enquiry
Semtech	SX1272	3.2 x 2.5 mm	32.000 MHz	10 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1276	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R	PDF	Request	Enquiry
Semtech	SX1276	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R	PDF	Request	Enquiry
Semtech	SX1276	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R	PDF	Request	Enquiry
Semtech	SX1276	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R	PDF	Request	Enquiry
Semtech	SX1276	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R	PDF	Request	Enquiry
Semtech	SX1276	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R	PDF	Request	Enquiry
Semtech	SX1276	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
Semtech	SX1276	3.2 x 2.5 mm	32.000 MHz	8 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
Semtech	SX1276	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Semtech	SX1276	3.2 x 2.5 mm	32.000 MHz	10 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1276	3.2 x 2.5 mm	32.000 MHz	10 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/10pF	PDF	Request	Enquiry
Semtech	SX1276	3.2 x 2.5 mm	32.000 MHz	10 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1231	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R	PDF	Request	Enquiry
Semtech	SX1231	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R	PDF	Request	Enquiry
Semtech	SX1231	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R	PDF	Request	Enquiry
Semtech	SX1231	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R	PDF	Request	Enquiry
Semtech	SX1231	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R	PDF	Request	Enquiry
Semtech	SX1231	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R	PDF	Request	Enquiry
Semtech	SX1231	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
Semtech	SX1231	3.2 x 2.5 mm	32.000 MHz	8 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
Semtech	SX1231	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Semtech	SX1231	3.2 x 2.5 mm	32.000 MHz	10 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1231	3.2 x 2.5 mm	32.000 MHz	10 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/10pF	PDF	Request	Enquiry
Semtech	SX1231	3.2 x 2.5 mm	32.000 MHz	10 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1231H	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R	PDF	Request	Enquiry
Semtech	SX1231H	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R	PDF	Request	Enquiry
Semtech	SX1231H	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R	PDF	Request	Enquiry
Semtech	SX1231H	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R	PDF	Request	Enquiry
Semtech	SX1231H	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R	PDF	Request	Enquiry
Semtech	SX1231H	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R	PDF	Request	Enquiry
Semtech	SX1231H	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
Semtech	SX1231H	3.2 x 2.5 mm	32.000 MHz	8 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
Semtech	SX1231H	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Semtech	SX1231H	3.2 x 2.5 mm	32.000 MHz	10 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1231H	3.2 x 2.5 mm	32.000 MHz	10 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/10pF	PDF	Request	Enquiry
Semtech	SX1231H	3.2 x 2.5 mm	32.000 MHz	10 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1232	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/8pF/40R	PDF	Request	Enquiry
Semtech	SX1232	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/8pF/40R	PDF	Request	Enquiry
Semtech	SX1232	2.0 x 1.6 mm	32.000 MHz	8 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/8pF/40R	PDF	Request	Enquiry
Semtech	SX1232	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/15/-40+85/10pF/40R	PDF	Request	Enquiry
Semtech	SX1232	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/10/-20+70/10pF/40R	PDF	Request	Enquiry
Semtech	SX1232	2.0 x 1.6 mm	32.000 MHz	10 pF	40 Ω	SMD02016/4 32.000 MHz 10/20/-40+85/10pF/40R	PDF	Request	Enquiry
Renesas	DA14585	3.2 x 2.5 mm	16.000 MHz	12 pF	85 Ω	SMD03025/4 16.000 MHz 10/20/-40+85/12pF	PDF	Request	Enquiry
Renesas	DA14585	3.2 x 1.5 mm	32.768 kHz	6pF	50 kΩ	M3215RR 32.768 kHz ±20 ppm 6pF (-40/+85°C)	PDF	Request	Enquiry
Renesas	DA14585	3.2 x 1.5 mm	32.768 kHz	7 pF	50 kΩ	M3215RR 32.768 kHz ±20 ppm 7pF (-40/+85°C)	PDF	Request	Enquiry
Renesas	DA14585	3.2 x 1.5 mm	32.768 kHz	9pF	50 kΩ	M3215RR 32.768 kHz ±20 ppm 9pF (-40/+85°C)	PDF	Request	Enquiry
Renesas	DA14585	1.6 x 1.0 mm	32.768 kHz	6pF	90 kΩ	M1610 32.768 kHz ±20 ppm 6pF (-40/+85°C)	PDF	Request	Enquiry
Renesas	DA14585	1.6 x 1.0 mm	32.768 kHz	7 pF	90 kΩ	M1610 32.768 kHz ±20 ppm 7pF (-40/+85°C)	PDF	Request	Enquiry
Renesas	DA14585	1.6 x 1.0 mm	32.768 kHz	9pF	90 kΩ	M1610 32.768 kHz ±20 ppm 9pF (-40/+85°C)	PDF	Request	Enquiry
Semtech	SX1232	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
Semtech	SX1232	3.2 x 2.5 mm	32.000 MHz	8 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
Semtech	SX1232	3.2 x 2.5 mm	32.000 MHz	8 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
Semtech	SX1232	3.2 x 2.5 mm	32.000 MHz	10 pF	30 Ω	SMD03025/4 32.000 MHz 10/15/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1232	3.2 x 2.5 mm	32.000 MHz	10 pF	25 Ω	SMD03025/4 32.000 MHz 10/10/-20+70/10pF	PDF	Request	Enquiry
Semtech	SX1232	3.2 x 2.5 mm	32.000 MHz	10 pF	30 Ω	SMD03025/4 32.000 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1280	2.0 x 1.6 mm	52.000 MHz	10 pF	50 Ω	SMD02016/4 52.000 MHz 10/10/-20+70/10pF	PDF	Request	Enquiry
Semtech	SX1280	2.0 x 1.6 mm	52.000 MHz	10 pF	50 Ω	SMD02016/4 52.000 MHz 10/15/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1280	2.0 x 1.6 mm	52.000 MHz	10 pF	50 Ω	SMD02016/4 52.000 MHz 10/50/-40+125/10pF/AUT	PDF	Request	Enquiry
Semtech	SX1280	2.0 x 1.6 mm	52.000 MHz	10 pF	50 Ω	SMD02016/4 52.000 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1280	3.2 x 2.5 mm	52.000 MHz	10 pF	25 Ω	SMD03025/4 52.000 MHz 10/15/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1280	3.2 x 2.5 mm	52.000 MHz	10 pF	25 Ω	SMD03025/4 52.000 MHz 10/10/-20+70/10pF	PDF	Request	Enquiry
Semtech	SX1280	3.2 x 2.5 mm	52.000 MHz	10 pF	25 Ω	SMD03025/4 52.000 MHz 10/50/-40+125/10pF/AUT	PDF	Request	Enquiry
Semtech	SX1280	3.2 x 2.5 mm	52.000 MHz	10 pF	25 Ω	SMD03025/4 52.000 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1281	3.2 x 2.5 mm	52.000 MHz	10 pF	25 Ω	SMD03025/4 52.000 MHz 10/15/-40+85/10pF	PDF	Request	Enquiry
Semtech	SX1281	3.2 x 2.5 mm	52.000 MHz	10 pF	25 Ω	SMD03025/4 52.000 MHz 10/10/-20+70/10pF	PDF	Request	Enquiry
Semtech	SX1281	3.2 x 2.5 mm	52.000 MHz	10 pF	25 Ω	SMD03025/4 52.000 MHz 10/50/-40+125/10pF/AUT	PDF	Request	Enquiry
Semtech	SX1281	3.2 x 2.5 mm	52.000 MHz	10 pF	25 Ω	SMD03025/4 52.000 MHz 10/20/-40+85/10pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	24.000 MHz	8 pF	60 Ω	SMD02016/4 24.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	24.000 MHz	12 pF	60 Ω	SMD02016/4 24.000 MHz 10/10/-20+70/12pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	24.000 MHz	8 pF	60 Ω	SMD02016/4 24.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	24.000 MHz	12 pF	60 Ω	SMD02016/4 24.000 MHz 10/15/-40+85/12pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	24.000 MHz	8 pF	60 Ω	SMD02016/4 24.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	24.000 MHz	12 pF	60 Ω	SMD02016/4 24.000 MHz 10/20/-40+85/12pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	50.000 MHz	8 pF	30 Ω	SMD02016/4 50.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	50.000 MHz	12 pF	30 Ω	SMD02016/4 50.000 MHz 10/10/-20+70/12pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	50.000 MHz	8 pF	30 Ω	SMD02016/4 50.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	26.000 MHz	12 pF	50 Ω	SMD02016/4 26.000 MHz 10/15/-40+85/12pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	50.000 MHz	8 pF	30 Ω	SMD02016/4 50.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	26.000 MHz	12 pF	50 Ω	SMD02016/4 26.000 MHz 10/20/-40+85/12pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	24.000 MHz	8 pF	60 Ω	SMD02016/4 24.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	24.000 MHz	12 pF	60 Ω	SMD02016/4 24.000 MHz 10/10/-20+70/12pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	24.000 MHz	8 pF	60 Ω	SMD02016/4 24.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	24.000 MHz	12 pF	60 Ω	SMD02016/4 24.000 MHz 10/15/-40+85/12pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	24.000 MHz	8 pF	60 Ω	SMD02016/4 24.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	24.000 MHz	12 pF	60 Ω	SMD02016/4 24.000 MHz 10/20/-40+85/12pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	48.000 MHz	8 pF	40 Ω	SMD02016/4 48.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	48.000 MHz	12 pF	40 Ω	SMD02016/4 48.000 MHz 10/10/-20+70/12pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	48.000 MHz	8 pF	40 Ω	SMD02016/4 48.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	48.000 MHz	12 pF	40 Ω	SMD02016/4 48.000 MHz 10/15/-40+85/12pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	48.000 MHz	8 pF	40 Ω	SMD02016/4 48.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	48.000 MHz	12 pF	40 Ω	SMD02016/4 48.000 MHz 10/20/-40+85/12pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	26.000 MHz	8 pF	50 Ω	SMD02016/4 26.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	26.000 MHz	8 pF	50 Ω	SMD02016/4 26.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	25.000 MHz	8 pF	50 Ω	SMD02016/4 25.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	25.000 MHz	12 pF	50 Ω	SMD02016/4 25.000 MHz 10/10/-20+70/12pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	48.000 MHz	8 pF	40 Ω	SMD02016/4 48.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	48.000 MHz	12 pF	40 Ω	SMD02016/4 48.000 MHz 10/10/-20+70/12pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	48.000 MHz	12 pF	40 Ω	SMD02016/4 48.000 MHz 10/20/-40+85/12pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	48.000 MHz	8 pF	40 Ω	SMD02016/4 48.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	48.000 MHz	12 pF	40 Ω	SMD02016/4 48.000 MHz 10/15/-40+85/12pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	48.000 MHz	8 pF	40 Ω	SMD02016/4 48.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	26.000 MHz	8 pF	50 Ω	SMD02016/4 26.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	25.000 MHz	8 pF	50 Ω	SMD02016/4 25.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	25.000 MHz	12 pF	50 Ω	SMD02016/4 25.000 MHz 10/15/-40+85/12pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	25.000 MHz	8 pF	80 Ω	SMD02016/4 25.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	25.000 MHz	12 pF	50 Ω	SMD02016/4 25.000 MHz 10/20/-40+85/12pF	PDF	Request	Enquiry
STM	SPIRIT1	2.0 x 1.6 mm	26.000 MHz	12 pF	50 Ω	SMD02016/4 26.000 MHz 10/10/-20+70/12pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	24.000 MHz	8 pF	30 Ω	SMD03025/4 24.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	24.000 MHz	12 pF	30 Ω	SMD03025/4 24.000 MHz 10/10/-20+70/12pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	24.000 MHz	8 pF	30 Ω	SMD03025/4 24.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	24.000 MHz	8 pF	30 Ω	SMD03025/4 24.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	25.000 MHz	8 pF	30 Ω	SMD03025/4 25.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	25.000 MHz	8 pF	30 Ω	SMD03025/4 25.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	50.000 MHz	12 pF	25 Ω	SMD03025/4 50.000 MHz 10/20/-40+85/12pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	50.000 MHz	8 pF	25 Ω	SMD03025/4 50.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	50.000 MHz	8 pF	25 Ω	SMD03025/4 50.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	50.000 MHz	8 pF	25 Ω	SMD03025/4 50.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	26.000 MHz	8 pF	30 Ω	SMD03025/4 26.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	26.000 MHz	8 pF	30 Ω	SMD03025/4 26.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	26.000 MHz	12 pF	30 Ω	SMD03025/4 26.000 MHz 10/15/-40+85/12pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	26.000 MHz	8 pF	30 Ω	SMD03025/4 26.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	26.000 MHz	12 pF	30 Ω	SMD03025/4 26.000 MHz 10/20/-40+85/12pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	48.000 MHz	8 pF	25 Ω	SMD03025/4 48.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	48.000 MHz	8 pF	25 Ω	SMD03025/4 48.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	48.000 MHz	12 pF	25 Ω	SMD03025/4 48.000 MHz 10/15/-40+85/12pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	48.000 MHz	8 pF	25 Ω	SMD03025/4 48.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	48.000 MHz	12 pF	25 Ω	SMD03025/4 48.000 MHz 10/20/-40+85/12pF	PDF	Request	Enquiry
STM	SPIRIT1	3.2 x 2.5 mm	48.000 MHz	12 pF	25 Ω	SMD03025/4 48.000 MHz 10/10/-20+70/12pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	25.000 MHz	8 pF	50 Ω	SMD02016/4 25.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	25.000 MHz	12 pF	50 Ω	SMD02016/4 25.000 MHz 10/10/-20+70/12pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	25.000 MHz	8 pF	50 Ω	SMD02016/4 25.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	25.000 MHz	12 pF	50 Ω	SMD02016/4 25.000 MHz 10/15/-40+85/12pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	25.000 MHz	8 pF	80 Ω	SMD02016/4 25.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	25.000 MHz	12 pF	50 Ω	SMD02016/4 25.000 MHz 10/20/-40+85/12pF	PDF	Request	Enquiry
STM	STM8AF/AL/S	5.0 x 3.2 mm	8.000 MHz	12 pF	150 Ω	SMD0503/4 8.000 MHz 10/10/-20+70/12pF/150R/500µW	PDF	Request	Enquiry
STM	STM8AF/AL/S	5.0 x 3.2 mm	8.000 MHz	12 pF	150 Ω	SMD0503/4 8.000 MHz 10/15/-40+85/12pF/150R/500µW	PDF	Request	Enquiry
STM	STM8AF/AL/S	5.0 x 3.2 mm	8.000 MHz	12 pF	150 Ω	SMD0503/4 8.000 MHz 10/20/-40+85/12pF/150R/500µW	PDF	Request	Enquiry
STM	STM8AF/AL/S	3.2 x 2.5 mm	8.000 MHz	12 pF	400 Ω	SMD03025/4 8.000 MHz 10/10/-20+70/12pF/400R/200µW	PDF	Request	Enquiry
STM	STM8AF/AL/S	3.2 x 2.5 mm	8.000 MHz	12 pF	500 Ω	SMD03025/4 8.000 MHz 10/10/-20+70/12pF/500R/500µW	PDF	Request	Enquiry
STM	STM8AF/AL/S	3.2 x 2.5 mm	8.000 MHz	12 pF	400 Ω	SMD03025/4 8.000 MHz 10/20/-40+85/12pF/400R/200µW	PDF	Request	Enquiry
STM	STM8AF/AL/S	3.2 x 2.5 mm	8.000 MHz	12 pF	500 Ω	SMD03025/4 8.000 MHz 10/15/-40+85/12pF/500R/500µW	PDF	Request	Enquiry
STM	STM8AF/AL/S	3.2 x 2.5 mm	8.000 MHz	12 pF	400 Ω	SMD03025/4 8.000 MHz 10/15/-40+85/12pF/400R/200µW	PDF	Request	Enquiry
STM	STM8AF/AL/S	3.2 x 2.5 mm	8.000 MHz	12 pF	500 Ω	SMD03025/4 8.000 MHz 10/20/-40+85/12pF/500R/500µW	PDF	Request	Enquiry
STM	STM8AF/AL/S	3.2 x 2.5 mm	16.000 MHz	12 pF	50 Ω	SMD03025/4 16.000 MHz 10/10/-20+70/12pF/50R/300µW	PDF	Request	Enquiry
STM	STM8AF/AL/S	3.2 x 2.5 mm	16.000 MHz	12 pF	50 Ω	SMD03025/4 16.000 MHz 10/15/-40+85/12pF/50R/300µW	PDF	Request	Enquiry
STM	STM8AF/AL/S	3.2 x 2.5 mm	16.000 MHz	12 pF	50 Ω	SMD03025/4 16.000 MHz 10/20/-40+85/12pF/50R/300µW	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	50.000 MHz	8 pF	25 Ω	SMD02016/4 50.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	50.000 MHz	12 pF	25 Ω	SMD02016/4 50.000 MHz 10/10/-20+70/12pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	50.000 MHz	8 pF	25 Ω	SMD02016/4 50.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	50.000 MHz	8 pF	25 Ω	SMD02016/4 50.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	26.000 MHz	8 pF	50 Ω	SMD02016/4 26.000 MHz 10/10/-20+70/8pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	26.000 MHz	12 pF	50 Ω	SMD02016/4 26.000 MHz 10/10/-20+70/12pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	26.000 MHz	8 pF	50 Ω	SMD02016/4 26.000 MHz 10/15/-40+85/8pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	26.000 MHz	12 pF	50 Ω	SMD02016/4 26.000 MHz 10/15/-40+85/12pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	26.000 MHz	8 pF	50 Ω	SMD02016/4 26.000 MHz 10/20/-40+85/8pF	PDF	Request	Enquiry
STM	S2-LP (SPIRIT-2)	2.0 x 1.6 mm	26.000 MHz	12 pF	50 Ω	SMD02016/4 26.000 MHz 10/20/-40+85/12pF	PDF	Request	Enquiry

FAQs

Welche Schwingquarze eignen sich für das Takten unterschiedlicher ICs?

Schwingquarze für das Takten unterschiedlicher ICs müssen elektrisch und mechanisch zur jeweiligen Anwendung passen. Laut Referenzliste von PETERMANN-TECHNIK können die angebotenen Quarze mit vielen verschiedenen ICs verwendet werden. Auch für weitere Bausteine sind passende Quarze aus dem breiten und tiefen Produktspektrum lieferbar. Besonders wichtig ist dabei ein sehr niedriger Widerstand, damit ein schnelles und sicheres Anschwingen erreicht wird. So lassen sich geeignete Schwingquarze gezielt für zahlreiche Taktanwendungen in der Elektronik auswählen.

Warum ist ein niedriger Widerstand bei Schwingquarzen für schnelles Anschwingen wichtig?

Ein sehr niedriger Widerstand ist bei Schwingquarzen entscheidend, wenn ein IC schnell und stabil getaktet werden soll. Dadurch wird das Anschwingen des Quarzes erleichtert und die Startzeit der Schaltung verbessert. Gerade bei schnellen elektronischen Anwendungen erhöht dies die Betriebssicherheit. PETERMANN-TECHNIK weist ausdrücklich darauf hin, dass entsprechende Quarze für sehr schnelles und sicheres Anschwingen lieferbar sind. Das ist besonders relevant, wenn Schwingquarze in anspruchsvollen oder neuen Designs eingesetzt werden.

Welche MHz-Schwingquarze empfiehlt PETERMANN-TECHNIK für Neuentwicklungen?

Für Neuentwicklungen empfiehlt PETERMANN-TECHNIK insbesondere MHz-Quarze der Serien SMD03025/4 und SMD2016/4. Die Serie SMD03025/4 besitzt ein Gehäuseformat von 3,2 x 2,5 mm mit 4 Pads und gilt aktuell als besonders günstiger miniaturisierter SMD-Quarz. Die Serie SMD2016/4 ist mit 2,0 x 1,6 mm noch kompakter ausgelegt. Beide Serien sind für moderne elektronische Anwendungen interessant, bei denen miniaturisierte SMD-Schwingquarze gefragt sind. Damit stehen Entwicklern passende Lösungen für neue Designs mit unterschiedlichen Platzanforderungen zur Verfügung.

Wann sollte ein SMD-Schwingquarz der Serie SMD02016/4 eingesetzt werden?

Ein SMD-Schwingquarz der Serie SMD02016/4 wird vor allem dann eingesetzt, wenn größere Bauformen für die Applikation nicht geeignet sind. PETERMANN-TECHNIK beschreibt diese Serie als Lösung für Anwendungen, bei denen der SMD03025/4 zu groß ist. Damit eignet sich der Quarz besonders für kompakte und miniaturisierte Elektronikdesigns. Entwickler profitieren von einer platzsparenden Bauform, ohne auf eine geeignete Taktquelle verzichten zu müssen. Gerade bei hoher Integrationsdichte ist diese Serie daher eine sinnvolle Wahl.

Welcher SMD-Schwingquarz ist für den Ultraschall-Verschließprozess geeignet?

Für den Ultraschall-Verschließprozess empfiehlt PETERMANN-TECHNIK den SMD-Schwingquarz der Serie SMD03025/4US. Diese Ausführung ist speziell für entsprechende Fertigungs- und Verarbeitungsprozesse vorgesehen. Damit erhalten Anwender einen Schwingquarz, der auf die Anforderungen dieses Montageverfahrens abgestimmt ist. Das ist besonders wichtig, wenn in der Produktion zuverlässige und prozesssichere SMD-Bauteile benötigt werden. So lässt sich der passende Quarz nicht nur nach elektrischen, sondern auch nach fertigungstechnischen Kriterien auswählen.

Warum PETERMANN-TECHNIK Schwingquarze?

PETERMANN-TECHNIK ist für Schwingquarze eine starke Wahl, weil das Unternehmen ein besonders breites und tiefes Produktspektrum anbietet. Dadurch sind passende Quarze für unterschiedliche ICs und viele weitere Taktanwendungen verfügbar. Für Neuentwicklungen werden konkrete und praxistaugliche Serien wie SMD03025/4, SMD2016/4 und SMD02016/4 empfohlen. Zudem stehen spezielle Lösungen wie der SMD03025/4US für den Ultraschall-Verschließprozess zur Verfügung. Ergänzt wird das Angebot durch persönliche Beratung durch Frequenz-Experten, die Kunden bei der Auswahl geeigneter Schwingquarze unterstützen.

Telefonisch contact

Onze frequentie-experts staan voor je klaar

Nu bellen

Schrijf ons

Stuur ons een e-mail - we helpen je graag verder

Schrijf ons nu
